FEATURES AT A GLANCE
- Symmetrical dual progressive roll tear resistant poly-cotton spiders
- Optimized and matched magnetic and complicance geometry
- Proprietary 8 AWG insulated allmetal input spring terminal connection
- Anodized aluminum heat sinking dust cap
- Kevlar fiber reinforced paper cone
- Periodic-stitched fatigue resistant tinsel lead wire
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Anodized aluminum voice coil former / copper clad aluminum wire
- Optimized pole piece and spider venting
- Rigid die-cast aluminum basket
- 1 Year Warranty
The Power Series T1D410 Dual 4-Ohm subwoofer builds on innovative new Rockford Fosgate technologies. These bad boys have patented VAST technology that increases surface cone area up to 25% so the T1D410 performs like a much larger woofer over the previous model. The new FlexFit basket not only looks the part but it provides extreme flexibility for extreme installations. Clean, high tech and ready to set off car alarms, the T1D410 is here!
Power Handling (Watts RMS)
600 Watts RMS
1200 Watts Max
1200 Watts Max
Nominal Impedance
Dual 4-Ohm
Magnet Weight (oz)
100 oz. (2.84 kg)
Size
10"
Voice Coil Diameter
3" (75.4mm)
SPL (dB @ 1w/1m)
83
Fs (Hz)
36
Woofer Displacement
0.078 cu. ft. (2.2 Liters)
Qes
0.73
Cutout Diameter
9.0625 in. (230 mm)
Sd (cm2)
345
Speaker Connector
Compression Terminal
Mounting Depth
6.375 in. (161.9 mm)
Qts
0.65
Shipping Weight
25.7 Lbs. (11.65 Kg.)
Qms
5.70
Vas (Liters)
15.7
Xmax (mm)
16
Re (Ohms)
6.50
Le (mH)
2.5
CEA-2031 Compliant
Subwoofer Type
Standard
Voice Coil Type
Dual Voice Coil
Sealed Box Volume (Vb)
0.75 cu. ft. (21.2 Liters)
Vented Box Volume (Vb)
1.5 cu. ft. (42.4 Liters)
